Alat ukur kekerasan metal dengan fitur lengkap:

1. Mendapatkan Sertifikat Kalibrasi

2. Pemakaian user-friendly: setting pilihan material dan satuan ukuran via tombol yang mudah dimengerti

3. Mengukur berbagai jenis metal: Besi, Baja, Stainless Steel, Aluminum, Tembaga, Perunggu, Kuningan, dll. Dengan Satuan HRC, HRB, HRA, HL, HB, HV atau HS

4. Built in printer: Hasil pengukuran bisa langsung diprint di tempat

5. Pengukuran bisa horisontal, dan vertikal

6. Fungsi alarm dengan set limit, ideal untuk pengecekan grup/ batch

====

Features

- User friendly: Easy operation

- Support 7 types of hardness scale

- Data memory: 373~2688 groups of data (including of the each measuring data, average value, date, impact direction, frequency, material, hardness unit, etc.)

- Alarm output: set the upper and lower values in, automatically alarm when it exceeds the limit, convenient for batch testing.

- Calibration function: With the indication software calibration function.

- Rechargeable lithium battery

- Software (Optional)

Hardness system:

Leeb (HL), Brinell (HB), Rockwell A (HRA), Rockwell B (HRB), Rockwell C (HRC), Vickers (HV) and Shore (HS)

Measuring range

HLD (170~960), HRA (59~85), HRB (13~100), HRC (18~68), HB (19~655), HV (80~976), HS (32~100)

Measuring direction

360° (vertical downward, obliquely downward, horizontal, oblique upward, vertical upward)

Measuring materials:

Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy, copper zinc alloy (brass), copper tin alloy (bronze), pure copper and forged steel.

Display: LCD, 128×64 graphics dot matrix

Print function: Thermal print head, quiet, ready to print results

Printing paper: width 57.5±0.5mm, diameter 30mm

Data storage: 373～2688 groups (impact times 32～1)

Communication interface: standard USB 2.0

Charging power supply: 9VDC, 220VAC

Charging time: 4 to 5 hours

Battery: 7.4V, lithium battery (1500mAh)

Storage temperature: -25～70°C

Application:

- Check the workpiece whether heat treatment and the effect of the heat treatment.

- Check the workpiece whether is inappropriate alloy processing.
