Colorimeter WR10

Colorimeter WR10
Colorimeter WR10 Colorimeter WR10 Colorimeter WR10 Colorimeter WR10 Colorimeter WR10 Colorimeter WR10
Product Code: WR10
Availability: In Stock
Price: Rp.6,800,000
Qty:
   - OR -
Colorimeter adalah alat pengukur warna. Kadang disebut alat pembaca warna (Color Reader)

Cara kerja alat ini dalam menentukan warna berdasarkan komponen warna Biru, Merah, serta Hijau dari cahaya yang terserap oleh objek atau sample material

Product description
Introduction:
▲Hand-held colorimeter WR10 is years of development of the high-precision colorimeter, developed according to the measuring requirements on different products and gain many optimal achievements with cost performance. Applicable in textile, printing and dyeing, clothing, footwear, leather, chemicals, plastics, film, pigments, paints, inks, metal, photography, toys, food medicine and other industry color quality control, color analysis, sample testing, production line testing, also suitable for injection molding, ink, paint, spray and other auxiliary color.

Features:
▲1.Through the SCM test
▲2.Simple, accurate, easy-to-use, convenient
▲3. Design in line with industry norms, good feel, easy to grasp, Steady body.
▲4. Clear and bright screen, large font display, intuitive chromaticity diagram color difference bias figure shows color simulation.
▲5. Advanced Power Management
Technical Specifications
▲Display mode: CIELAB
▲Color difference formula: ΔE *ab
▲Illumination Condition: CIE Recommendation:8/d
▲Light Source: D65
▲Sensor: Photodiode array
▲Measuring Aperture: Φ8mm
▲Measuring Condition: Observer:CIE 10° Standard observer
▲Measuring Range: L:0-100
▲Repeated Accuracy: ΔE<0.08
▲Table Difference: ΔE <0.2
▲Measurement Time: 1 second
▲Storage Capacity: 100 standard samples and10000 test sample
▲Battery Power supply: Li-ion battery, 5000 times Measurement
▲Lifetime of Bulb: 5years more than 160 million measuring
▲Display screen: TFT true color 2.8inch@(16:9)
▲Interface of External: USB2.0 (USB-B), RS-232 (115200bps)
▲Working Temperature Range: 0°C-40°C (32°F-104°F)
▲Storage Temperature Range: -20°C-50°C (-4°F-122°F)
▲Humidity Range: Relative humidity less than 85%,without condensation
▲Net Weight: 700g
▲Dimension: 199x68x90mm
